| Brand | Johnson |
| Series | SMP |
| Type | Standard |
| Termination Type | Solderless |
| Termination Style | Printed Circuit Board |
| Gender | Plug |
| Mounting Style | Vertical Launch |
| Body Style | Straight |
| Body Material | Beryllium Copper |
| Body Finish | Gold |
| Contact Material | Beryllium Copper |
| Contact Plating | Gold |
| Insulator | PTFE |
| Max Frequency (GHz) | 40 |
| Durability (Cycles Min) | 100 |
| Operating Temp. Range (°C) | -65 to +165 |
| Impedance (Ohms) | 50 |
| Working Voltage (Vrms) | 335 |
| Insulation Resistance (mOhms Min) | 5000 |
| Insertion Loss (dB Max) | 0.76 |
| Number of Ports | 1 |
