Rectangular Accessories
We offer additional components to compliment and enhance the functionality of our rectangular connectors, including tools, backshells, and dust caps.
Product Categories
Product Resources
Attribute Filters
Accessory Type
Used With
Backshell Type
Brand
For Connector Type
Base Material
Color
Plating Material
Assembly Torque (Nm)
Assembly Tool
59 Products
Show Filters
Hide Filters
| Product | Accessory Type | Used With | Backshell Type | For Connector Type | Base Material | Color | Plating Material | Assembly Torque (Nm) | Assembly Tool |
|---|---|---|---|---|---|---|---|---|---|
| Backshell | C-ENX B1 | Strain relief | Composite | N/A | 0.8 | C-282666002 | |||
| Backshell | C-ENX A | Strain relief | Composite | N/A | 0.8 | C-282666002 | |||
| Backshell | C-ENX B1 | 45º Strain relief | Composite | N/A | 0.8 | C-282666002 | |||
| Backshell | C-ENX A | 45º Strain relief | Composite | N/A | 0.8 | C-282666002 | |||
| Backshell | C-ENX B1 | Strain relief | Aluminum | Anodized | 0.8 | C-282666002 | |||
| Backshell | C-ENX Galley Connector (ARINC 810) | Strain relief | Composite | N/A | 0.8 | C-282664, C-282665 | |||
| Backshell | C-ENX B2 | Strain relief | Aluminum | Anodized | 1.2 | C-282664, C-282665 | |||
| Backshell | C-ENX Rack & Panel | Strain relief | Composite | N/A | 0.55 | N/A | |||
| Backshell | C-ENX B1 | EMI protection | Aluminum | Nickel-plated | 0.8 | C-282666002 | |||
| Backshell | C-ENX B2 | EMI protection | Aluminum | Nickel-plated | 1.2 | C-282664, C-282665 | |||
| Backshell | C-ENX B2 | EMI protection | Aluminum | Nickel-plated | 1.2 | C-282664, C-282665 | |||
| Backshell | C-ENX B1 | EMI protection | Aluminum | Nickel-plated | 1.2 | Allen wrench, C-282664, C-282665 | |||
| Backshell | C-ENX Rack & Panel | EMI protection | Aluminum | Nickel-plated | 0.55 | N/A | |||
| Backshell | C-ENX B1 | EMI protection | Composite | Nickel-plated | 0.8 | C-282666002 | |||
| Backshell | C-ENX B2 | EMI protection | Composite | Nickel-plated | 1.2 | Allen wrench 1/4 inch | |||
| Polarization key | Series .156 | N/A | N/A | ||||||
| Filler Plug | C-ENX Galley Connector (ARINC 810) | Plug | N/A | ||||||
| Sealing Insert | C-ENX B1 | Socket | N/A | ||||||
| Sealing Insert | C-ENX B1 | Pin | N/A | ||||||
| Sealing Insert | C-ENX A | Socket | N/A | ||||||
| Sealing Insert | C-ENX A | Pin | N/A | ||||||
| Dust Cap | C-ENX Galley Connector (ARINC 810) | Plug | Pink | ||||||
| Dust Cap | C-ENX Galley Connector (ARINC 810) | Receptacle | Pink | ||||||
| Dust Cap | C-ENX B2 | Plug | Black | ||||||
| Dust Cap | C-ENX B2 | Receptacle | Black |
Catalog
Strain relief Backshell used with plug assembly kit C-617610189
Composite
Non-plated
Composite
Non-plated
For Fly Away Application
Mateable with C-ENX B1 Socket Insert used with C-ENX B1
Mateable with C-ENX B1 Socket Insert used with C-ENX B1
Esd Version Dust Cap for C-ENX B2 Plug Shell (Black) used with C-ENX B2 and C-ENX Rack and Panel
Esd Version Dust Cap for C-ENX B2 Receptacle Shell (Black) used with C-ENX B2 and C-ENX Rack and Panel
Loading more products . . .
