Stacking & Compression Jumpers and Assemblies
Cinch's stacking jumpers and assemblies offer flexible connections for diverse board-to-board setups, allowing for segmented rigid-flex-rigid PCB designs without replacing the entire assembly. Customizable for various lengths and pinouts, they provide versatile solutions for electronic applications.
Product Resources
Capability Page
CIN::APSE®
Attribute Filters
Positions
Width (in)
2 Products
Show Filters
Hide Filters
| Product | Drawing | 3D Model | Positions | Length (in) | Width (in) | Thickness (in) | Material | Alignment Holes | Mounting Holes |
|---|---|---|---|---|---|---|---|---|---|
|
25 | 3.0 | 1.10 | 0.008 | LF0210 Coverlay / AP9121 Core | 4x 0.036" | 4x 0.090" | ||
|
|
51 | 3.0 | 1.75 | 0.008 | LF0210 Coverlay / AP9121 Core | 4x 0.036" | 4x 0.090" |
