RF & Microwave DC Blocks
Cinch's DC blocks are designed to block direct current (DC) signals while allowing alternating current (AC) signals to pass through, ensuring proper isolation in your RF and microwave systems. Engineered to work across a wide frequency range with minimal insertion loss and low VSWR, they are built for durability, providing stable performance even in harsh environments.
Attribute Filters
Series Side 1
Series Side 2
Gender 1
Gender 2
Max Frequency (GHz)
Body Material
11 Products
Show Filters
Hide Filters
| Product | Brand | Series Side 1 | Series Side 2 | Gender 1 | Gender 2 | Max Frequency (GHz) | Body Material | Body Style | Body Finish | Contact Plating | Impedance (Ohms) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Midwest Microwave | SMA | SMA | Female | Female | 18.5 | Stainless Steel | Straight | Passivated | Gold | 50 | |
| Midwest Microwave | SMA | SMA | Male | Female | 18.5 | Stainless Steel | Straight | Passivated | Gold | 50 | |
| Midwest Microwave | SMA | SMA | Male | Male | 18.5 | Stainless Steel | Straight | Passivated | Gold | 50 | |
| Midwest Microwave | SMA | SMA | Male | Female | 18.5 | Delrin | Straight | N/A | Gold | 50 | |
| Midwest Microwave | N Type | N Type | Male | Female | 18 | Delrin | Straight | N/A | Gold | 50 | |
| Midwest Microwave | N Type | N Type | Male | Female | 18 | Delrin | Straight | N/A | Gold | 50 | |
| Midwest Microwave | TNC | TNC | Male | Female | 18 | Delrin | Straight | N/A | Gold | 50 | |
| Midwest Microwave | TNC | TNC | Male | Female | 18 | Delrin | Straight | N/A | Gold | 50 | |
| Midwest Microwave | SMA | SMA | Male | Female | 12.4 | Delrin | Straight | N/A | Gold | 50 | |
| Midwest Microwave | SMA | SMA | Male | Female | 18 | Delrin | Straight | N/A | Gold | 50 | |
| Midwest Microwave | 7mm | 7mm | Male | Female | 18 | Delrin | Straight | N/A | Gold | 50 |
