Features & Specifications
| Series | MCX |
| Type | Non-Magnetic |
| Termination Type | Full Crimp |
| Termination Style | Cable |
| Gender | Jack |
| Cable Type | RG161, RG174, RG179, RG187 |
| Mounting Style | Cable Mount |
| Body Style | Straight |
| Body Material | Copper Alloy |
| Body Finish | Gold |
| Contact Material | Beryllium Copper |
| Contact Plating | Gold |
| Insulator | PTFE |
| Max Frequency (GHz) | 6 |
| Durability (Cycles Min) | 500 |
| Operating Temp. Range (°C) | -65 to +165 |
| Impedance (Ohms) | 50 |
| Working Voltage (Vrms) | 335 |
| Insulation Resistance (mOhms Min) | 1000 |
| Insertion Loss (dB Max) | 0.1 |
| Number of Ports | 1 |
| Brand | Johnson |
