Features & Specifications
| Series | mini-FAKRA |
| Type | Standard |
| Termination Type | Solder |
| Termination Style | Printed Circuit Board |
| Gender | Jack |
| Mounting Style | PCB Mount |
| Body Style | Right Angle |
| Body Material | Plastic |
| Contact Material | Brass |
| Contact Plating | Gold |
| Max Frequency (GHz) | 9 |
| Durability (Cycles Min) | 25 |
| Operating Temp. Range (°C) | -40 to +105 |
| Impedance (Ohms) | 50 |
| Working Voltage (Vrms) | 335 |
| Insulation Resistance (mOhms Min) | 1000 |
| Number of Ports | 4 |
| Brand | Stewart Connector |
