CN0942 Series - Short Receptacle Connectors (Fluorosilicone Inserts)
ConnectorsThe Omega CN0942 Series connectors are designed for high-performance applications, specifically for custom board mount, flex circuit, and soldered wire configurations. These connectors adhere to MIL-C-26500 military specifications, ensuring they meet rigorous electrical and mechanical requirements. The CN0942 connectors feature fixed contacts and a low-profile shell, making them ideal for space-constrained applications.
Options and Variations
- Shell Sizes:Available in sizes 8, 10, 12, 14, 16, 18, 20, 22, and 24.
- Coupling Styles:Offered in bayonet and threaded coupling styles.
- Contact Styles:Includes pin and socket contacts, with options for potted-in configurations.
- Materials:Shells are constructed from aluminum with finishes such as hard anodized type III, standard anodized type II, electroless nickel, cadmium over electroless nickel, and stainless steel with a passivated finish.
- Environmental Sealing:Neoprene inserts provide robust environmental sealing, suitable for various applications, while still meeting MIL-C-26500 standards for fluid resistance, and vibration.
Special Attributes:
- Mounting Options:Includes single-hole, square flange, knurled panel, standoffs, and clinch nuts.
- Termination Options:Offers PC tails for circuit board or flex, solder cup for discrete wire, and square posts for wire wrap.
